AUTO /MAN control panel, for IRRIGATION MOTOR PUMP

Features:

• Valid for Diesel and Petrol engines.
• Three position selector key:

•    0: Disconnected: group shutdown and reset.
•    M: Manual: Start up and shutdown via button.
•    A: Automatic: Operation / Shutdown by means of external command.

• Running time programmer.
• Motor pump protección by means of 8 alarms

4 Measurement Instruments Included

• RPM
• Battery voltage
• Record of running hours.
• Running time programmer

Connector type MATE-N-LOK 18 Terminals

IP65 Protection rating

Antivibration isolation type SILENT BLOCK

Technical Especifications

• Battery Voltage:                               10-35Vdc
• Consumption in  stand-by mode:       2mA with 12V batteries
• Dimensions:                                    160X200122,6mm
• Weitgh:                                           900 gr.
