SAM 716
High technology, small size AUTO MAN programmable genset controller with monophasic monitoring of principal electrical parameters
Features
- For diesel and petrol engines,
- Selector by key with three positions:
- 0: Disconnected/genset shutdown and reset
- M: Manual: Startup and shutdown via switch
- A: Automatic operation (remote control)
- Adaptable to any type of genset programming by means of the display and front panel buttons
- Selectable heater of spark plugs or starter
- Automatic connection/disconnection of the generator contactor
- Shutdown by solenoid or electro valve
- High power outputs, avoid supplementary relay
- Protected against vibration
- Fuel tank level
- AC Voltmeter Max. between phases: 500VAC
- AC Ammeter Max. 1.250 Amp
- Frequency meter Frequency:50 / 60 Hz
- Hour counter Maintenance management
- Battery voltmeter Battery voltage
Weekly and immediate programmable clock
28 Programable parameters without extra tool
Alarms
- Low oil pressure
- Water overheating
- Low fuel level
- Broken belts or battery alternator fault
- Emergency stop
- Overspeed
- Optional alarm
Configuration and monitoring via PC connected with USB port cable
Technical Specifications
- Battery Voltage: 10-35 Vcc
- Consumption in stand-by mode: 2 mA with 12VDC batteries
- Dimensions: 96x96x82,5 mm
- Weight: 350 g
